| REVUEFLEX
TL25 |
| Producer data |
| Producer |
Kombinat VEB Pentacon
Dresden |
responsible constructor |
Rolf Noack |
| production period |
1983 |
no of produced cameras |
as a part of MTL 5-series (574,252) |
| Technical properties of the camera |
| shutter type |
mechanically controlled vertical-moving metal-blade focal plane shutter |
exposure time
(possible settings) |
B, 1/1, 1/2, 1/4, 1/8, 1/15 1/30, 1/60,
1/125, 1/250,1/500, 1/1000 |
| view finder |
fixed eye-level view finder (Pentaprism)
with Fresnel lens with microprism and plain split-image range finder as focusing screen, built-in
shutter speed meter with (+/-)-symbol |
mirror |
instant-return mirror |
| film transport / frame counter |
quick-release lever (black), Pentacon
Loading-System, fold-out rewind crank (black), auto-zeroing frame counter |
lens mount |
M42x1 |
| self timer |
mechanically, approx. 10 sec |
battery |
VARTA V 625 |
| metering system |
TTL-metering using stopped-down metering controlled by a switch beside the lens mount above the shutter release knob |
flash system |
X-synchronisation (1/125), accessory shoe at the top of the pentaprism, coaxial flash socket at the camera body for dual flash systems |
| flash indication |
none |
aperture reflection into view finder |
none |
| general comments |
smooth, unruffled leatherette with stampings |
| collection data |
| Hummel-No |
210 |
Kadlubek-No. |
REV 0801 |
| body no. |
1397001 |
lens no. |
0901 |
| lens type |
Pentacon auto 2.8/29 MC |
purchase price |
28$ |
| advertising |
|
manual |
|
|
