| Hanimex
Pro TL |
| Producer data |
| Producer |
Kombinat VEB
Pentacon Dresden |
responsible constructor |
Herbert Welzel |
| production period |
1969 to 1975 |
no of produced cameras |
as a part of Praktica super
TL-series (508,656) |
| Technical properties of the camera |
| shutter type |
mechanically controlled horizontal-run
rubberised cloth-blind type shutter |
exposure time
(possible settings) |
B, 1/1, 1/2, 1/4, 1/8, 1/15 1/30, 1/60,
1/125, 1/250,1/500 |
| view finder |
fixed eye-level view finder (Pentaprism)
with Fresnel lens and microprism range finder as focusing screen, built-in
shutter speed meter |
mirror |
instant-return mirror |
| film transport / frame counter |
quick-release lever, Pentacon
Loading-System, fold-out rewind crank |
lens mount |
M42x1 |
| self timer |
none |
battery |
VARTA V 625 |
| metering system |
TTL-exposure meter using CdS-photoresistor
(cadmium sulphide) used with a innovative beam-splitter in the pentaprism using stopped-down metering |
flash system |
X- and F-synchronisation with
two flash coaxial sockets at the bottom of the front of the camera body |
| flash indication |
none |
aperture reflection into view finder |
none |
| general comments |
 | Hanimex-version of
Praktica super TL |
|
| collection data |
| Hummel-No |
166 |
Kadlubek-No. |
none |
| body no. |
none |
lens no. |
3974033 |
| lens type |
Meyer-Optik Goerlitz Domiplan
2.8/50 |
purchase price |
74 € |
| advertising |
|
manual |
|
|
